某八层框架宾馆、旅馆毕业设计

来源:56doc.com  资料编号:5D2477 资料等级:★★★★★ %E8%B5%84%E6%96%99%E7%BC%96%E5%8F%B7%EF%BC%9A5D2477
资料以网页介绍的为准,下载后不会有水印.资料仅供学习参考之用. 帮助
资料介绍

摘   要
本次毕业设计是一幢宾馆设计,包括建筑设计和结构设计两部分内
容。
建筑设计是在总体规划的前提下,根据设计任务书的要求,综合考虑基地环境、使用功能、综合选型、施工、材料、建筑设备、建筑艺术及经济等。着重解决了建筑物与周围环境、建筑物与各种细部构造,最终确定设计方案,画出建筑施工图。
结构设计是在建筑物初步设计的基础上确定结构方案;选择合理的结构体系;进行结构布置,并初步估算,确定结构构件尺寸,进行结构计算。结构计算包括荷载计算、变形验算、内力分析及截面设计,并绘制相关的结构施工图。
本工程为旅馆设计,因地处城市中心交通要道,在总体规划设计时,考虑到场地要求、绿化设施、其它功能要求,以及周围建筑物的影响,设计时采用矩形。
总之,适用、安全、经济、使用方便是本设计的原则,两部分空间合理,连接紧凑,主次分明,使建筑空间的舒适度加以提高。

关键词:抗震  D值法  结构  配筋  桩基础

ABSTRACT
This design is a scheme of a hotel building it includes two parts-architecture design and structure design.
In the architecture design. In the architecture design and structure designing the architecture design, I compressively consider the base averment using faction, structure type, construction building materials equipment architecture economy and architecture economy and architecture art act.. Then I mainly solve using space in this building and coordination between inside and outside conditions.
In the structure design, determine the structure design based on architecture first design. Select the right structure type. Precede structure arrangement and sizes of structure components to calculate. All work about calculation including load estimation deform test. Mechanics analysis and selection design, In the end, drawing all the blueprints of architecture construction and structure constructor.
This project is designed for certain commercial hotel building . because of land place city center traffic important line, in the design of overall planning , ask and afforest as far as place is concerned the influence of facility, other function requirement and as well as around building, adopt design junxing type.
In a word, suitable, safety, economy and use facilitate is the principle of design, two parts` space reasonable, join compact, primary and secondary distinct, make the comfortable degree of building space rise.

Key word:Anti-seismic stake foundation lighting structure

工程概况:
某宾馆设计楼,主体八层,钢筋混凝土框架结构。梁板柱均为现浇,建筑面积约为6908m2,建筑物平面为矩形,受场地限制,宽15.6米,长为55.36米,建筑方案确定,房间开间3.6m,进深6.6m,走廊宽2.4m,底层层高3.9m,其它层高3.3m,室内外高差为0.45m,设防烈度7度,一类场地。地震参数区划的特征周期分区为二区,抗震等级二级。

地理位置
本宾馆设计位于一城市主干道,另一侧的次干道是一条步行街,建筑沿街外轮廓线较好的联系了两条街道。大面积的玻璃窗和门不仅仅为建筑中庭提供了充足的采光,也将城市空间引入建筑内部。

建筑设计说明
本设计为某旅馆的建筑设计,总建筑面积为6908m2,拟建8层。
本设计共分为以下几个部分:
建筑平面的设计;
建筑剖面的设计;
建筑体型和立面的设计;
抗震设计;
房屋层数的确定和剖面的组合形式:
建筑空间的组合和利用
旅馆设计的基本要求














目    录
1 绪论 4
1.1 工程背景 4
2 建筑设计说明 4
2.1 建筑平面的设计 5
2.2 建筑体型和立面设计 6
2.3 抗震设计 8
2.4 房屋层数的确定和剖面的组合形式 10
2.5 建筑空间的组合和利用 11
2.6旅馆设计的基本要求 12
3 结构设计说明书 18
3.1框架结构设计 18
3.2 框架结构设计计算 19
4 标准层楼梯的设计 93
4.1 基本设计依据 93
(毕业设计)
4.2 梯段板 TB-1板的计算 94
4.3 梯段板TB-2平台板计算 96
4.4 平台梁TL-1计算 98
5 首层楼梯的设计 100
5.1基本设计依据 100
5.2梯段板 TB-1板的计算 100
5.3 TB-2平台板计算 102
5.4 平台梁TL-1计算 104
5.5 平台梁在砖墙上的支承长度验算 105
6 楼板设计 106
6.1设计资料 106
6.2 荷载计算 106
7基础设计 113
7.1 地质条件 113
7.2单桩承载力验算 113
7.3承台的厚度验算 116

参考文献 118
致谢 119

参考文献
1. 单健 吕令毅主编.结构力学东南大学出版社,2004
2. 龙驭球 包世华主编.结构力学教程.高等教育出版社,2003
3. 曹双寅主编.工程结构设计原理.东南大学出版社,2002
4. 邱洪兴等编.建筑结构设计.东南大学出版社,2002
5. 李爱群 高振世主编.工程结构抗震与防灾.东南大学出版社,2003
6. 石名磊 龚维明等编.基础工程.东南大学出版社,2002
7. 郭正兴 李金根主编.建筑施工.东南大学出版社,2003
8. 中华人民共和国建设部.GB50010-2002.混凝土结构设计规范.中国建筑工业出版社.2002
9. 中华人民共和国建设部.GB50011-2001.建筑抗震设计规范.中国建筑工业出版社.2001
10. 中华人民共和国建设部.GB50007-2002.建筑地基基础规范.中国建筑工业出版社.2002
11. 中华人民共和国建设部.GB50009-2001.建筑结构荷载规范.中国建筑工业出版社.2001
12. 建筑结构静力计算手册.中国建筑工业出版社
13. 建筑结构构造手册.中国建筑工业出版社
