Design and analysis of battery system for heavy-duty unmanned electric container transportation vehicle
Abstract
With the development of the port logistics which are going for large-scale, large-flow, high-speed. Large-scale container ships, large-tonnage containers, and the loading, unloading equipment and the supporting large-scale shore bridges have been built for it. This article mainly designs and analyzes the battery system of heavy-duty unmanned electric container transporter. After consulting the literature, and analyzing the environmental conditions and working requirements of the port AGV, finally GYS LIM50H-12 lithium ion battery is chosen as the battery module for the project, according to the data of the electric drive system from my partner to calculate the required power and he requirements of the target model to design The parameters of the electric vehicle system reasonably, determine the basic structure of a single battery pack, that is, 8 battery cells are connected in parallel to form a battery module, and 8 battery modules are connected in series to form a power battery pack. I designed the overwrap and the fixed way of the battery pack in view of the design of the car's driving conditions and speed. Simplified the battery cell model for temperature field analysis.
Key words: pure electric vehicle, battery pack, mechanical structure, thermal analysis
目录
Chapter 1 Chapter Introduction 5
1.1 background and significance 5
1.2 research developments and trends at home and abroad: 6
1.2.1 Domestic Research Developments 6
1.2.2 Research Trends Abroad 6
Chapter 2 chapter battery pack Mechanical structure Design 8
2.1 Basic requirements for the design of the battery pack mechanical structure 8
2.2 Determination of basic parameters for battery pack 9
2.2.1 Power System Parameters 9
2.2.2 Determine the basic parameters of the power system 9
2.2.3 Determination of power system capacity 9
2.2.4 structure of the power system 10
2.2.5 Battery pack Framework Design 12
2.3 Battery Module Design 14
2.3.1 bus and copper nose design. 14
2.3.2 Battery Module Specific Energy 16
2.3.3 Processing technology for battery modules 16
2.4 battery pack Structure Design 17
2.4.1 placement of the battery module in the battery pack 17
2.4.2 Battery fixed structure design 17
2.4.3 design of battery pack cooling structure 18
2.5 Battery pack Box design 22
2.6 battery pack model and physical drawings 24
2.7 Summary of this chapter 25
Chapter 3 Battery pack Thermal Analysis 26
3.1 theoretical basis of the thermal model of lithium-ion batteries 26
3.1.1 thermal principle of lithium-ion battery 26
3.1.2 Heat transfer inside the battery 28
3.1.3 how the battery and external heat transfer 30
3.2 Lithium-ion battery thermal model establishment 32
3.2.1 Building a battery thermal model 32
3.2.2 determination of cooling mode and simplification of simulation conditions 33
3.2.3 Battery Thermal Analysis 34
3.3 Summary of this chapter 36
Chapter 4 The summary and Prospect 36
4.1 summary 36
4.2 prospects 37
References (Bold second number) 37
Thanks 38
|
