室内空气质量检测仪的设计(任务书,开题报告,论文15000字)
摘 要
随着经济社会的发展，人们的生活水平日益提高，对环境问题及其可能引发的健康隐患也日益重视。尤其是与日常生活密切相关的室内空气质量开始成为关注的焦点。本文研究的是一种室内空气质量检测系统，能够对室内的甲醛、一氧化碳、氧气及温度、湿度进行实时监测，当有害气体浓度超标时及时报警，以提醒人们及时采取相应的措施。
室内空气质量检测仪以超低功耗AT89S52为控制芯片，以电化学式4OXV其及半导体电阻式MQ-7、MQ-138传感器为感应元件，采用LCD1602点阵式液晶屏显示，有良好的人机对话界面，同时兼有声光报警模块，实时显示室内气体浓度和超标示警。该系统还设计了前级滤波放大电路，对传感器输出的微弱信号进行放大处理并通过AD0809进行模数转换，以减小测量误差。因此该室内空气质量检测系统具有良好的测量精度，操作简单，性能优良，适用于一般室内空气检测，保护人们的健康安全。
关键词：室内空气质量；AT89S52单片机；传感器；LCD显示
Abstract
With the development of national economy and improvement of people's living standard, awareness of environmental problems and their possible health risks are increasingly put more attention. Especially indoor air quality which is closely related to the daily life became the focus of attention. This study is on an indoor air quality testing system, capable of real-time monitoring of indoor formaldehyde, carbon monoxide, oxygen ,temperature and humidity. When the concentration of harmful gas exceeds the standard,it will alert people to take timely and appropriate measures in time.
Indoor air quality testing system uses ultra-low-power chip AT89S52 as the control chip, electrochemical 4OXV and semiconductor resistive MQ-7, MQ-138 as the sensor sensing element. It uses LCD1602 dot matrix as LCD display,with a good man-machine dialog interface and equips with both sound and light alarm module which can perform real-time display of gas concentration and excessive indoor warning. The system also designs the pre-filter amplifier circuit, and the weak signal of the sensor output is amplified and processed by analog to digital converter AD0809,which can reduce measurement error. Therefore,the indoor air quality testing system has good accuracy, simple structure, excellent performance, for general indoor air testing, to protect people's health and safety.
Key words：indoor air quality；AT89S52 chip；sensor；LCD display
